Power Supply: PSD12
In car power supply

Feature:

Wide input voltage 11VDC to 26VDC
for Model PSD 12-0 to PSD 12-2
Wide input voltage 11VDC to 15 VDC
for Model PSD 12-4 to PSD 12-8
Optional output connectors
High reliability
High efficiency
Compact low profile package
One year warranty



NOTE:

1. Weight: Approx 70~100g

2. Optional output connectors:

Model Output Voltage Output Current Maximum Output Power
PSD12-0 3~5VDC 1.0~0.60A 3W
PSD12-1 5~6VDC 1.00~0.83A 5W
PSD12-1-1 6~8VDC 1.00~0.75A 6W
PSD12-2 8~11VDC 1.00~0.72A 8W
PSD12-4 13~16VDC 0.61~0.50A 8W
PSD12-5 16~21VDC 0.50~0.38A 8W
PSD12-6 21~27VDC 0.38~0.29A 8W
PSD12-7 17~33VDC 0.29~0.24A 8W
PSD12-8 33~48VDC 0.24~0.16A 8W
